Delta FFB0412SHN-9F89 12V DC Cooling Fan
- Product SKU: CFS-U001506
- Category: 12 Volt DC Cooling Fans, DC Brushless Fans, Delta Cooling Fans
Confirm Fit Before Ordering
Use this quick check first, then review the full Product Specifications tab before placing an order.
Share the original fan label, connector photo, or target quantity so the team can check compatibility or quote bulk supply.
Reference model: FFB0412SHN-9F89
Product Specifications
Review the technical data used for replacement matching, procurement comparison and engineering approval.
Historical listing photographs - verify the supplied unit
The retained complete historical rear label reads Delta FFB0412SHN, -9F89, DC12V 0.60A, with 1613a/06R markings. The alternative watermarked front photograph is retained in store records outside this gallery.
The thick square frame, four-colour lead bundle and pale plug appearance do not establish the actual supplied connector pitch/keying, pin assignment or current stock.
These are historical listing photographs, including earlier image preparation or restoration where recorded; they are not confirmation of current shipping stock or supplied condition. Complete alternative listing photographs are retained in store records outside this gallery. Confirm the complete offered model and option, actual electrical label, measured mounting dimensions, condition, lead arrangement, connector keying and pin assignment before ordering. No equipment compatibility, control function, measured performance or units per order are inferred.
Delta FFB0412SHN-9F89 specifications and selection
The original listing photograph shows Delta model FFB0412SHN-9F89, marked 12V DC and 0.6 A. The current is a nameplate value; normal input current and maximum current are not independently confirmed for this exact version.
| Full photographed model | FFB0412SHN-9F89 |
|---|---|
| Photographed voltage | 12V DC |
| Nameplate current | 0.6 A (nameplate; nominal and maximum not confirmed) |
| Visible leads | 4 (photograph only; signal function unconfirmed) |
| Dimensions and mounting | Not confirmed for this OEM version |
| Airflow, speed, pressure and noise | Not confirmed for this OEM version |
| Bearing, power and operating-voltage range | Not confirmed for this OEM version |
| Connector and electrical signals | Fitted connector and pinout not confirmed; PWM and feedback functions not established |
What should I check before ordering?
Compare the full label, dimensions, mounting and fitted connector with your existing fan. A matching base model or visible lead count does not establish equipment compatibility or signal functions. Performance specifications from other suffixes are not applied to this version.
Retained historical rear-label photograph
For help comparing the full label and connector, send a fan photo.
Compatibility Verification Checklist
Before ordering, please confirm these critical points:
- 1Exact model number on the original fan label
- 2Frame size: length, width and thickness
- 3Rated voltage and current
- 4Connector type and wire sequence
- 5Wire count: 2-wire, 3-wire or 4-wire PWM
- 6Airflow direction and mounting hole position
- 7Cable length and application environment
Still unsure? Send us photos of your fan label, connector and equipment. We will help check compatibility before you order.
Datasheet / Drawing
Use official documents and dimensional references when available. If a document is missing, contact us before ordering for replacement matching support.
Bulk Order
For repair batches, OEM projects or distributor replenishment, send the model number, target quantity, connector requirements and delivery destination.
Shipping & Returns
Shipping options, lead time and return eligibility may vary by product, quantity and destination. Confirm compatibility before ordering replacement fans.
- For bulk orders, request freight planning and availability confirmation before payment.
- For replacement orders, compare model, size, voltage, current and connector before installation.
- Unused items should remain in original condition for return review according to store policy.
FAQ
Common checks for replacement cooling fan sourcing.
Can you help match an old fan?
Yes. Send photos of the fan label, connector and equipment so we can check model, voltage, frame size and wiring.
Can I use a different brand as a replacement?
Often yes, but only after confirming frame size, electrical rating, airflow requirement, bearing type, connector and wire sequence.
What information is needed for a bulk quote?
Send part number, quantity, target lead time, connector or cable requirements and shipping destination.
