SUNON KDE2412PMB1-6A (7).B305.GN 24V DC Axial Fan
- Product SKU: CFS-U001769
- Category: 24V DC Cooling Fans, DC Brushless Fans, SUNON Cooling Fans
Confirm Fit Before Ordering
Use this quick check first, then review the full Product Specifications tab before placing an order.
Share the original fan label, connector photo, or target quantity so the team can check compatibility or quote bulk supply.
Reference model: KDE2412PMB1-6A (7).B305.GN
Product Specifications
Review the technical data used for replacement matching, procurement comparison and engineering approval.
KDE2412PMB1-6A (7).B305.GN label and selection
The original listing photographs identify this SUNON axial fan as KDE2412PMB1-6A (7).B305.GN. The values below are a transcription of the photographed unit, not an independent performance test.
| Manufacturer on label | SUNON |
|---|---|
| Photographed complete model / option | KDE2412PMB1-6A (7).B305.GN |
| Nameplate voltage | 24V DC |
| Nameplate power | 10.3W |
| Visible fitted leads | 2; signal functions not established |
| Mechanical and performance data | Exact-version drawing and performance are not confirmed |
Which version should I match?
Match the complete KDE2412PMB1-6A (7).B305.GN code. The added option distinguishes the photographed version; a shared base model does not establish equal wiring or performance.
What else should I verify?
The label prints 10.3W as power. It is not an ampere rating; current and connector signal functions remain unconfirmed for this exact version.
Product listing photograph. For a comparison, send a fan photo; for quantities, request a quote.
External rear-view reference — verify supplied version: The existing seller photograph from EquipSpares shows SUNON KDE2412PMB1-6A (7).B305.GN, DC24V and 10.3W, with two red/black leads and a black connector housing. Source auxiliary print F3351B is readable; the historical auxiliary marks are not confidently transcribed. The source has a longer dark sleeve than the shorter exposed segment in the historical listing view, and connector presentation and pose differ. These photographs do not establish identical harness length, sleeving, supplied ordering option, connector pitch/keying, condition or pinout. Photographic identity and prior third-party processing history have not been independently verified. This is not an untouched-original recovery or proof of current shipping stock. Confirm the actual full ordering option, electrical label, measured dimensions, harness, connector and pin assignment before ordering. The printed 10.3W is power, not an ampere rating; wire colours do not establish signal functions. The historical full listing photograph is retained in store records outside this gallery.
