Original listing front photograph of SUNON cooling fan and fitted red/black cable with white plug; match the rear label and verify supplied dimensions and pinout.
Original listing rear-label photograph showing SUNON KD1205PHS3, separate GN, DC12V0.7W and visible red/black leads; power is not current, and supplied exact version requires verification.
Original listing front photograph of SUNON cooling fan and fitted red/black cable with white plug; match the rear label and verify supplied dimensions and pinout.
Original listing rear-label photograph showing SUNON KD1205PHS3, separate GN, DC12V0.7W and visible red/black leads; power is not current, and supplied exact version requires verification.
Technical media Confirm label, connector and fit
Original listing front photograph of SUNON cooling fan and fitted red/black cable with white plug; match the rear label and verify supplied dimensions and pinout. Fan label photo
Original listing front photograph of SUNON cooling fan and fitted red/black cable with white plug; match the rear label and verify supplied dimensions and pinout. Dimension drawing
SUNON

SUNON KD1205PHS3 GN 12V DC 0.7W Axial Cooling Fan

Available: Confirm availability
Compatibility checkpoint

Confirm Fit Before Ordering

Use this quick check first, then review the full Product Specifications tab before placing an order.

Before ordering: Compare the original fan label, frame size, rated voltage/current, connector, wire count, airflow direction and mounting holes.
Confirm availability View full specifications Send fan photos
Price
$25.19
Need confirmation before ordering?

Share the original fan label, connector photo, or target quantity so the team can check compatibility or quote bulk supply.

Request Bulk Quote Ask Compatibility Check Send Fan Photos

Reference model: KD1205PHS3

Product Specifications

Review the technical data used for replacement matching, procurement comparison and engineering approval.

Label and supplied-version verification: The original listing label shows SUNON KD1205PHS3 with separate GN, DC12V and 0.7W. The 0.7W marking is power, not a current rating; no current is calculated from it. Supplied exact-version dimensions, electrical current, performance, connector and pin assignment require verification. The catalog reference below and photographed label are distinct evidence.

KD1205PHS3 related catalog reference

The following historical catalog transcription is a related KD1205PHS3 reference, not confirmation of the pictured GN version or the unit currently supplied. Its catalog dimensions, current, bearing and performance must be verified against the complete supplied version.

Manufacturer SUNON
Exact model KD1205PHS3
Frame 50 x 50 x 15 mm
Rated voltage 12V DC
Bearing 2-ball bearing
Rated current 0.055 A
Power 0.7 W
Speed 3700 RPM
Maximum airflow 10.2 CFM
Maximum static pressure 0.12 inH2O
Noise 23 dB(A)
Lead count 2 wires

Evidence boundary: Connector shell and pinout are not stated in the cited catalog; match them to the original fan.

How do I verify replacement compatibility?

Match the complete model and suffix, all three frame dimensions, rated voltage, mounting-hole pattern, airflow direction, lead count, connector shell and pinout. A matching width alone does not establish electrical compatibility.

What should I send for a compatibility check?

Send clear photos of the original fan label and connector plus the equipment model. The physical fan label is product-identity evidence and should remain visible.

CoolingFanStore is a specialist multi-brand cooling-fan retailer operated by Guangzhou Yougu Electronic Technology Co., Ltd. SUNON identifies the fan manufacturer, not the store operator.

Specification source

SUNON KD1205PHS3 catalog copy. Historical related-model reference; this catalog transcription does not establish the pictured GN version or supplied dimensions, current or performance.

Replacement confirmation

Compatibility Verification Checklist

Before ordering, please confirm these critical points:

  1. 1
    Exact model number on the original fan label
  2. 2
    Frame size: length, width and thickness
  3. 3
    Rated voltage and current
  4. 4
    Connector type and wire sequence
  5. 5
    Wire count: 2-wire, 3-wire or 4-wire PWM
  6. 6
    Airflow direction and mounting hole position
  7. 7
    Cable length and application environment

Still unsure? Send us photos of your fan label, connector and equipment. We will help check compatibility before you order.

Send Fan Photos Ask for Compatibility Check

Datasheet / Drawing

Use official documents and dimensional references when available. If a document is missing, contact us before ordering for replacement matching support.

Datasheet URL View datasheet
Dimension drawing View drawing image

Bulk Order

For repair batches, OEM projects or distributor replenishment, send the model number, target quantity, connector requirements and delivery destination.

Reference model KD1205PHS3
Manufacturer / brand SUNON
Request Bulk Quote

Shipping & Returns

Shipping options, lead time and return eligibility may vary by product, quantity and destination. Confirm compatibility before ordering replacement fans.

  • For bulk orders, request freight planning and availability confirmation before payment.
  • For replacement orders, compare model, size, voltage, current and connector before installation.
  • Unused items should remain in original condition for return review according to store policy.

FAQ

Common checks for replacement cooling fan sourcing.

Can you help match an old fan?

Yes. Send photos of the fan label, connector and equipment so we can check model, voltage, frame size and wiring.

Can I use a different brand as a replacement?

Often yes, but only after confirming frame size, electrical rating, airflow requirement, bearing type, connector and wire sequence.

What information is needed for a bulk quote?

Send part number, quantity, target lead time, connector or cable requirements and shipping destination.
