SUNON PSD1204PQBX-A 40x40x28mm 12V DC Axial Cooling Fan
- Product SKU: CFS-U003252
- Category: 12 Volt DC Cooling Fans, 40x40x28mm Cooling Fans, DC Brushless Fans, SUNON Cooling Fans
Confirm Fit Before Ordering
Use this quick check first, then review the full Product Specifications tab before placing an order.
Share the original fan label, connector photo, or target quantity so the team can check compatibility or quote bulk supply.
Reference model: PSD1204PQBX-A
Product Specifications
Review the technical data used for replacement matching, procurement comparison and engineering approval.
Historical listing photographs - supplied unit verification required
This gallery retains the existing complete listing views without seller-watermark overlays. The retained complete historical rear view shows SUNON PSD1204PQBX-A (2).B4600.F.GN with printed DC12V 9.60W. These are historical listing images, including earlier image preparation where applicable; they are not confirmation of current shipping stock or supplied condition.
The alternative watermarked front photograph is retained in store records outside this gallery. Confirm the complete offered model and electrical label, actual mounting dimensions, condition, lead arrangement, connector keying and pinout before ordering. Photographs and lead colours do not establish signal functions, equipment compatibility or performance.
Technical Specifications
| Brand | SUNON |
| Mfr. Part Number | PSD1204PQBX-A |
| Frame Size | 40x40x28mm |
| Rated Voltage | 12V DC |
| Product Category | Industrial Cooling Fan |
Notice: Professional industrial component. Verify technical parameters before selection.
Compatibility Verification Checklist
Before ordering, please confirm these critical points:
- 1Exact model number on the original fan label
- 2Frame size: length, width and thickness
- 3Rated voltage and current
- 4Connector type and wire sequence
- 5Wire count: 2-wire, 3-wire or 4-wire PWM
- 6Airflow direction and mounting hole position
- 7Cable length and application environment
Still unsure? Send us photos of your fan label, connector and equipment. We will help check compatibility before you order.
Datasheet / Drawing
Use official documents and dimensional references when available. If a document is missing, contact us before ordering for replacement matching support.
Bulk Order
For repair batches, OEM projects or distributor replenishment, send the model number, target quantity, connector requirements and delivery destination.
Shipping & Returns
Shipping options, lead time and return eligibility may vary by product, quantity and destination. Confirm compatibility before ordering replacement fans.
- For bulk orders, request freight planning and availability confirmation before payment.
- For replacement orders, compare model, size, voltage, current and connector before installation.
- Unused items should remain in original condition for return review according to store policy.
FAQ
Common checks for replacement cooling fan sourcing.
Can you help match an old fan?
Yes. Send photos of the fan label, connector and equipment so we can check model, voltage, frame size and wiring.
Can I use a different brand as a replacement?
Often yes, but only after confirming frame size, electrical rating, airflow requirement, bearing type, connector and wire sequence.
What information is needed for a bulk quote?
Send part number, quantity, target lead time, connector or cable requirements and shipping destination.
